KW6
KW6 High Speed Computerized Lock Stitch Shuttle Multi Needle Quilting Machine
● Fully Automatic lubricating oil system for shuttle shaft (optional),reduces manual maintenance, can better prolong the service life of spare parts, and can improve work efficiency. Fashionable appearance, integrated electric box design, save space for users.
● New shuttle guide rail support structure, using U-shaped bearing guide, shaft and bearing perfectly fit, making more durable and stable.
● Advanced computer control system and mechanical manufacturing process reduce machine noise.
● The needle bar design of needles connect bar frame without lube, avoid to dirty fabrics, the structure is not easy to damage, low maintenance costing.
● The main shaft is controlled by frequency converter for automatically lifting the needle, and the saddle and roller are driven by servo.
Technical data at a glance:
Model | KW6(66'') | KW6(96'') | KW6(128'') |
Quilt width(mm) | 1650 | 2450 | 3300 |
Quilt thickness(mm) | ≤30 | ≤30 | ≤30 |
Needle bar space(mm) | 76.2+50.8+38.1+25.4 | 76.2+50.8+38.1+25.4 | 76.2+50.8+38.1+25.4 |
Needle space(mm) | 25.4 | 25.4 | 25.4 |
Needle Type | 14#-21# | 14#-21# | 14#-21# |
X-stroke(mm) | 204 | 305 | 305 |
Stitch(mm) | 3-8 | 3-8 | 3-8 |
Spindle speed(rpm) | 500-1100 | 500-1100 | 500-1100 |
Output(m/h) | 60-160 | 70-155 | 70-150 |
Motor power(kw) | 5.5 | 5.5 | 6.5 |
